New technologies inside
- Screw mounted guide, not a clip-in
- Guide has wide spaced braid positioning to suit wood tracks and Policar and Ninco track
- Guide has front mounted grub screws for securing braid - they push against the braid as a flat surface
- 3 Body posts - two at front makes body float and tilt easy to set up and control
- Plastic rear hubs fitted and a pair of Alloy rears under the box
- Shallow cockpit, clipped in (not glued or heat fixed), for easy removal, cleaning or replacing with a lexan one
- Elongated screw holes in chassis to enable longitudinal body float
- Has the new fixing for digital chips and the connector for plug and play digital
Length: 154mm
Width: 65mm
Height: 38mm
Rear wheels to Guide post triangle: 103mm
Track (outside of tyres): 62mm
Total weight: 72.7 g (without magnet)
Body weight: 22.7g
Chassis: Podded with 0.5mm offset Motor: Slot.it MX16m 23,000rpm mounted as sidewinder
Guide: New screw mount guide
Axle & Gears - 2.38mm (3/32nd)
Gearing: Crown 32t - Pinion 11t brass
Has adjustable height front axle
Hubs: Front 17.3 x 8mm - plastic Hubs: Rear 17.3mm x 8mm Plastic wheels fitted, with a pair of 17.2 x 9.75mm alloy wheels under the box Tyres: Front PT1167c1 Tyres: Rear PT1167c1
SSD Upgradable: Yes, use Slot.it chip SP15b
For wood track racing, we recommend replacing the rear tyres with Slot.it PT1172N22
